Drilling, Milling and Tapping Machine

Description

Description/Specification:

▪ Drilling capacity: Φ40mm
▪ Face milling capacity: 80mm
▪ End milling capacity: 32mm
▪ Distance from spindle nose to table: 450mm
▪ Distance from spindle to column: 260mm
▪ Spindle travel: 130mm
▪ Spindle taper: MT4, R8
▪ Spindle speed steps: 6steps
▪ Spindle speed range (50HZ): 80-1250rpm
▪ Spindle speed range (60HZ): 95-1500rpm
▪ Swivel angle of headstock: ±90°
▪ Table size: 800×240mm
▪ Forward-backward travel of table: 175mm
▪ Left-right travel of table: 500mm
▪ Motor power: 1.1kw
▪ N.W/G.W: 320/370kg
▪ Packing size (L×W×H): 770×880×1160mm

Included:
▪ Allen wrench
▪ Wedge
▪ Tie rod
▪ Operation manual (English)
▪ Base
▪ Power feeder
▪ 3-axis DRO
