Saddle Moving Type Surface Grinder

Description

Description/Specification:

▪ Table size: 200×508mm
▪ Electro magnetic chuck size: 200×460mm
▪ Distance from spindle to table: 450mm
▪ Table cross travel: 240mm
▪ Table longitudinal travel: 560mm
▪ Loading capacity (include chuck): 180kg
▪ Longitudinal feed speed: 5-25m/min
▪ Table cross intermittent feed rate: 0.1-8mm/str
▪ Table cross rapid feed speed: 990mm/min
▪ Table cross feed of handwheel: 0.02mm/gra
▪ Wheelhead vertical intermittent feed rate: 0.005-0.5mm/str
▪ Wheelhead vertical rapid feed speed: 480mm/min
▪ Wheelhead vertical feed of handwheel: 0.005mm/gra
▪ Spindle speed (50/60HZ): 2850/3450rpm
▪ Grinding wheel size: Φ200×20×Φ31.75mm
▪ Main motor power: 2.2kw
▪ Package dimensions (L×W×H): 1900×2050×2100mm
▪ Machine weight: 1650kg

Included: ▪ Balancing arbor ▪ Standing grinding wheel ▪ Magnetic chuck ▪ Built-in magnetic chuck controller ▪ Coolant tank ▪ Work lamp ▪ Wheel flange and extractor ▪ Wheel dresser stand ▪ Lubrication system ▪ Tool box & tools ▪ Leveling wedge and screw ▪ Operational manual (English) ▪ Balance stand ▪ Magnetic separator & paper filter
