Shapping Machine

Description

Specification

Maximum planing length 500 mm
Max range of the horizontal movement of the table 370 mm
Max distance between the ram bottom and table 525 mm
Max length of the vertical movement of table 270 mm
Dimensions of table top L x W 500 x 360 mm
Max stroke length of the toolhead 120 mm
Number of ram reciprocation per minute 14 80 times min
Max swivel angle of the toolhead -+60
Number of ram reciprocation per minute 20 x 30 mm
Range of table feed Power 0 2 2 5 Overall 0 08 1 0
Width of the T slot for center positioning 18 mm
Power of the main motor 3kw
Overall dimensions L x W x H 200 x 1250 x 1400 mm
N W G W 1650 1760 kg
